ESD15VD5 15V esd protection diodes electrostatical Discharge Protect

FOB Reference Price:Get Latest Price
$0.02 - $0.04 / Piece | 3000 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 3000 >3000
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Brand Name:
YINT, YINT
Model Number:
ESD15VD5
Place of Origin:
Shanghai, China (Mainland)
Type:
ESD15VD5
Package:
SOD523
Packing:
3000Pcs/ Reel
Operating voltage:
15V
Supply Ability
Supply Ability:
500000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
envalope for small quantity, carton for large quantity
Port
Shanghai Port
Lead Time :
Quantity(Pieces) 1 - 3000 >3000
Est. Time(days) 7 To be negotiated

01 02

     ESD15VD5 is designed to protect voltage sensitive components from ESD and transient voltage envents. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium.

ESD8V0D5 SOD-523ESD1

03



200 Watts Peak Pulse Power per Line (tp=8/20µs)

Operating voltage: 15V

Low leakage current

Package: SOD-523

Low clamping voltage

Complies with following standards:

  – IEC 61000-4-2 (ESD) immunity test

 Air discharge: ±15kV

 Contact discharge: ±8kV



Applications



Cellular Handsets and Accessories

Portable Electronics

Industrial Controls

Set-Top Box

Instrumentation

Servers, Notebook, and Desktop PC

Display Ports



  Absolute Maximum Ratings



Parameter

Symbol

Value

Unit

Peak Pulse Power (8/20µs)

PPP

200

Watts

ESD per IEC 61000−4−2 (Air)

VESD

±15

KV

ESD per IEC 61000−4−2 (Contact)

±8

KV

Lead Soldering Temperature

TL

260 (10 sec)

°C

Operating Temperature Range

TJ

-55 to +125

°C

Storage Temperature Range

TSTJ

-55 to +150

°C






 Electrical Characteristics (T =25°C)



Electrical C

haracteristi





Parameter



Symbol



Conditions



Min.



Typ.



Max.



Units

Reverse Stand-off Voltage

VRWM







15

V

Reverse Breakdown Voltage

VBR

It  = 1mA

16.6





V

Reverse Leakage Current

IR

VR  =VRWM





1

μA

Clamping Voltage

VC

IPP=1A,    tP = 8/20μs





21

V

Clamping Voltage

VC

IPP=5A,    tP = 8/20μs





35

V

Junction Capacitance

CJ

VR=0V, f = 1MHz





50

pF



s (T =25°C
